Standard ECV plugin interface. More...
#include <ecvStdPluginInterface.h>
Public Member Functions | |
| ccStdPluginInterface (const QString &resourcePath=QString()) | |
| Default constructor. More... | |
| virtual | ~ccStdPluginInterface () override=default |
| Destructor. More... | |
| virtual CC_PLUGIN_TYPE | getType () const override |
| Returns plugin type (standard or OpenGL filter) More... | |
| virtual void | setMainAppInterface (ecvMainAppInterface *app) |
| Sets application entry point. More... | |
| virtual ecvMainAppInterface * | getMainAppInterface () |
| A callback pointer to the main app interface for use by plugins. More... | |
| virtual QList< QAction * > | getActions ()=0 |
| Get a list of actions for this plugin. More... | |
| virtual void | onNewSelection (const ccHObject::Container &selectedEntities) |
| virtual void | dispToConsole (QString message, ecvMainAppInterface::ConsoleMessageLevel level=ecvMainAppInterface::STD_CONSOLE_MESSAGE) |
| Shortcut to ecvMainAppInterface::dispToConsole. More... | |
 Public Member Functions inherited from ccDefaultPluginInterface | |
| virtual | ~ccDefaultPluginInterface () |
| virtual bool | isCore () const override |
| Is this plugin a core plugin? More... | |
| virtual QString | getName () const override |
| Returns (short) name (for menu entry, etc.) More... | |
| virtual QString | getDescription () const override |
| Returns long name/description (for tooltip, etc.) More... | |
| virtual QIcon | getIcon () const override |
| Returns icon. More... | |
| virtual ReferenceList | getReferences () const override |
| virtual ContactList | getAuthors () const override |
| virtual ContactList | getMaintainers () const override |
| Public Member Functions inherited from ccPluginInterface | |
| virtual | ~ccPluginInterface ()=default |
| Virtual destructor. More... | |
| virtual bool | start () |
| Starts the plugin. More... | |
| virtual void | stop () |
| Stops the plugin. More... | |
| virtual ccExternalFactory * | getCustomObjectsFactory () const |
| Returns the plugin's custom object factory (if any) More... | |
| virtual void | registerCommands (ccCommandLineInterface *cmd) |
| Optional: registers commands (for the command line mode) More... | |
Protected Attributes | |
| ecvMainAppInterface * | m_app |
| Main application interface. More... | |
Additional Inherited Members | |
| Public Types inherited from ccPluginInterface | |
| typedef QList< Contact > | ContactList |
| using | ReferenceList = QList< Reference > |
| Protected Member Functions inherited from ccDefaultPluginInterface | |
| ccDefaultPluginInterface (const QString &resourcePath=QString()) | |
Standard ECV plugin interface.
Version 1.5 The plugin is now responsible for its own actions (QAction ;) and the associated ecvMainAppInterface member should give it access to everything it needs in the main application.
Definition at line 31 of file ecvStdPluginInterface.h.
|
inline |
Default constructor.
Definition at line 34 of file ecvStdPluginInterface.h.
|
overridevirtualdefault |
Destructor.
|
inlinevirtual |
Shortcut to ecvMainAppInterface::dispToConsole.
Definition at line 74 of file ecvStdPluginInterface.h.
References ecvMainAppInterface::dispToConsole(), and m_app.
|
pure virtual |
Get a list of actions for this plugin.
Implemented in qSRA, PythonPlugin, qPCV, qMPlane, qCSF, and q3DMASCPlugin.
|
inlinevirtual |
A callback pointer to the main app interface for use by plugins.
Any plugin (and its tools) may need to access methods of this interface
Definition at line 59 of file ecvStdPluginInterface.h.
References m_app.
|
inlineoverridevirtual |
Returns plugin type (standard or OpenGL filter)
Implements ccPluginInterface.
Definition at line 41 of file ecvStdPluginInterface.h.
References ECV_STD_PLUGIN.
|
inlinevirtual |
This method is called by the main application whenever the entity selection changes Does nothing by default. Should be re-implemented by the plugin if necessary.
| selectedEntities | currently selected entities |
Reimplemented in qSRA, qPCV, qMPlane, qCSF, and q3DMASCPlugin.
Definition at line 69 of file ecvStdPluginInterface.h.
Referenced by ccPluginUIManager::handleSelectionChanged().
|
inlinevirtual |
Sets application entry point.
Called just after plugin creation by qCC
Reimplemented in PythonPlugin.
Definition at line 46 of file ecvStdPluginInterface.h.
References ecvMainAppInterface::getUniqueIDGenerator(), m_app, and ccObject::SetUniqueIDGenerator().
Referenced by ccPluginUIManager::init(), and PythonPlugin::setMainAppInterface().
|
protected |
Main application interface.
Definition at line 85 of file ecvStdPluginInterface.h.
Referenced by ccCompass::addGeoObject(), qFacets::classifyFacetsByAngle(), ccCompass::cleanupBeforeToolChange(), qSRA::computeCloud2ProfileRadialDist(), ccCompass::convertToPointCloud(), qFacets::createFacets(), dispToConsole(), ccCompass::distributeSelection(), qCloudLayers::doAction(), ccCompass::doAction(), qCork::doAction(), qCSF::doAction(), qHoughNormals::doAction(), qMPlane::doAction(), qPCV::doAction(), qPoissonRecon::doAction(), qRansacSD::doAction(), qTreeIso::doAction(), q3DMASCPlugin::doClassifyAction(), qCanupoPlugin::doClassifyAction(), qSRA::doComputeRadialDists(), qSRA::doProjectCloudDistsInGrid(), q3DMASCPlugin::doTrainAction(), qCanupoPlugin::doTrainAction(), ccCompass::enableMapMode(), ccCompass::enableMeasureMode(), ccCompass::estimateP21(), ccCompass::estimateStrain(), ccCompass::estimateStructureNormals(), JsonRPCPlugin::execute(), qFacets::exportFacets(), qFacets::exportFacetsInfo(), ccCompass::exportToSVG(), qFacets::extractFacets(), qTreeIso::final_segs(), ccCompass::fitPlaneToGeoObject(), qFacets::getFacetsInCurrentSelection(), ccCompass::getInsertPoint(), getMainAppInterface(), ccCompass::importFoliations(), ccCompass::importLineations(), qTreeIso::init_segs(), qTreeIso::intermediate_segs(), qSRA::loadProfile(), ccCompass::mergeGeoObjects(), q3DMASCPlugin::onNewSelection(), ccCompass::onSave(), ccCompass::pointPicked(), qSRA::projectCloudDistsInGrid(), ccCompass::recalculateFitPlanes(), ccCompass::recalculateSelectedTraces(), ccCompass::setLineation(), setMainAppInterface(), PythonPlugin::setMainAppInterface(), ccCompass::setPick(), ccCompass::setPlane(), ccCompass::setThickness(), ccCompass::setTrace(), ccCompass::setYoungerThan(), ccCompass::showHelp(), qFacets::showStereogram(), ccCompass::startMeasuring(), ccCompass::startPicking(), ccCompass::stopMeasuring(), ccCompass::stopPicking(), ccCompass::toggleLabels(), ccCompass::toggleNormals(), ccCompass::toggleStipple(), ccCompass::tryLoading(), and ccCompass::writeToXML().
