e57::FloatNodeImpl Class Reference

#include <FloatNodeImpl.h>

Inheritance diagram for e57::FloatNodeImpl:

Collaboration diagram for e57::FloatNodeImpl:

Public Member Functions
	FloatNodeImpl (ImageFileImplWeakPtr destImageFile, double value=0, FloatPrecision precision=E57_DOUBLE, double minimum=E57_DOUBLE_MIN, double maximum=E57_DOUBLE_MAX)
	~FloatNodeImpl () override=default
NodeType	type () const override
bool	isTypeEquivalent (NodeImplSharedPtr ni) override
bool	isDefined (const ustring &pathName) override
double	value () const
FloatPrecision	precision () const
double	minimum () const
double	maximum () const
void	checkLeavesInSet (const StringSet &pathNames, NodeImplSharedPtr origin) override
void	writeXml (ImageFileImplSharedPtr imf, CheckedFile &cf, int indent, const char *forcedFieldName=nullptr) override
void	dump (int indent=0, std::ostream &os=std::cout) const override
Public Member Functions inherited from e57::NodeImpl
void	checkImageFileOpen (const char *srcFileName, int srcLineNumber, const char *srcFunctionName) const
bool	isRoot () const
NodeImplSharedPtr	parent ()
ustring	pathName () const
ustring	relativePathName (const NodeImplSharedPtr &origin, ustring childPathName=ustring()) const
ustring	elementName () const
ImageFileImplSharedPtr	destImageFile ()
ustring	imageFileName () const
bool	isAttached () const
virtual void	setAttachedRecursive ()
void	setParent (NodeImplSharedPtr parent, const ustring &elementName)
bool	isTypeConstrained ()
virtual NodeImplSharedPtr	get (const ustring &pathName)
virtual void	set (const ustring &pathName, NodeImplSharedPtr ni, bool autoPathCreate=false)
virtual void	set (const StringList &fields, unsigned level, NodeImplSharedPtr ni, bool autoPathCreate=false)
void	checkBuffers (const std::vector< SourceDestBuffer > &sdbufs, bool allowMissing)
bool	findTerminalPosition (const NodeImplSharedPtr &target, uint64_t &countFromLeft)
virtual	~NodeImpl ()=default

Additional Inherited Members
Protected Member Functions inherited from e57::NodeImpl
	NodeImpl (ImageFileImplWeakPtr destImageFile)
NodeImpl &	operator= (NodeImpl &n)
virtual NodeImplSharedPtr	lookup (const ustring &)
NodeImplSharedPtr	getRoot ()
Protected Attributes inherited from e57::NodeImpl
ImageFileImplWeakPtr	destImageFile_
NodeImplWeakPtr	parent_
ustring	elementName_
bool	isAttached_

Detailed Description

Definition at line 33 of file FloatNodeImpl.h.

Constructor & Destructor Documentation

FloatNodeImpl()

e57::FloatNodeImpl::FloatNodeImpl	(	ImageFileImplWeakPtr	destImageFile,
		double	value = 0,
		FloatPrecision	precision = E57_DOUBLE,
		double	minimum = E57_DOUBLE_MIN,
		double	maximum = E57_DOUBLE_MAX
	)

Since this ctor also used to construct single precision, and defaults for minimum/maximum are for double precision, adjust bounds smaller if single.

Enforce the given bounds on raw value

Definition at line 33 of file FloatNodeImpl.cpp.

References e57::E57_ERROR_VALUE_OUT_OF_BOUNDS, E57_EXCEPTION2, e57::E57_SINGLE, maximum(), minimum(), e57::NodeImpl::pathName(), e57::toString(), and value().

~FloatNodeImpl()

e57::FloatNodeImpl::~FloatNodeImpl ( )

overridedefault

Member Function Documentation

checkLeavesInSet()

void e57::FloatNodeImpl::checkLeavesInSet ( const StringSet &  pathNames, NodeImplSharedPtr  origin  )

overridevirtual

We are a leaf node, so verify that we are listed in set (either relative or absolute form)

Implements e57::NodeImpl.

Definition at line 132 of file FloatNodeImpl.cpp.

References e57::E57_ERROR_NO_BUFFER_FOR_ELEMENT, E57_EXCEPTION2, e57::NodeImpl::pathName(), and e57::NodeImpl::relativePathName().

dump()

void e57::FloatNodeImpl::dump ( int  indent = 0, std::ostream &  os = std::cout  ) const

overridevirtual

Save old stream config

Restore old stream config

Reimplemented from e57::NodeImpl.

Definition at line 212 of file FloatNodeImpl.cpp.

References e57::NodeImpl::dump(), e57::E57_SINGLE, QtCompat::endl(), precision(), e57::space(), and type().

isDefined()

bool e57::FloatNodeImpl::isDefined ( const ustring &  pathName )

overridevirtual

We have no sub-structure, so if path not empty return false

Implements e57::NodeImpl.

Definition at line 100 of file FloatNodeImpl.cpp.

References e57::NodeImpl::pathName().

isTypeEquivalent()

bool e57::FloatNodeImpl::isTypeEquivalent ( NodeImplSharedPtr  ni )

overridevirtual

Same node type?

Downcast to shared_ptr<FloatNodeImpl>

precision must match

minimum must match

maximum must match

ignore value_, doesn't have to match

Types match

Implements e57::NodeImpl.

Definition at line 63 of file FloatNodeImpl.cpp.

References e57::E57_FLOAT.

maximum()

double e57::FloatNodeImpl::maximum

(

)

const

Definition at line 126 of file FloatNodeImpl.cpp.

References e57::NodeImpl::checkImageFileOpen().

Referenced by FloatNodeImpl().

minimum()

double e57::FloatNodeImpl::minimum

(

)

const

Definition at line 120 of file FloatNodeImpl.cpp.

References e57::NodeImpl::checkImageFileOpen().

Referenced by FloatNodeImpl().

precision()

FloatPrecision e57::FloatNodeImpl::precision

(

)

const

Definition at line 114 of file FloatNodeImpl.cpp.

References e57::NodeImpl::checkImageFileOpen().

Referenced by dump().

type()

NodeType e57::FloatNodeImpl::type ( ) const

inlineoverridevirtual

Implements e57::NodeImpl.

Definition at line 40 of file FloatNodeImpl.h.

References e57::E57_FLOAT.

Referenced by dump().

value()

double e57::FloatNodeImpl::value

(

)

const

Definition at line 108 of file FloatNodeImpl.cpp.

References e57::NodeImpl::checkImageFileOpen().

Referenced by FloatNodeImpl().

writeXml()

void e57::FloatNodeImpl::writeXml ( ImageFileImplSharedPtr  imf, CheckedFile &  cf, int  indent, const char *  forcedFieldName = nullptr  )

overridevirtual

Don't need to write if are default values

Write value as child text, unless it is the default value

Don't need to write precision="double", because that's the default

Don't need to write if are default values

Write value as child text, unless it is the default value

Implements e57::NodeImpl.

Definition at line 145 of file FloatNodeImpl.cpp.

References e57::E57_SINGLE, e57::NodeImpl::elementName_, and e57::space().

---

The documentation for this class was generated from the following files:

• /root/ACloudViewer/plugins/core/IO/qE57IO/extern/libE57Format/src/FloatNodeImpl.h
• /root/ACloudViewer/plugins/core/IO/qE57IO/extern/libE57Format/src/FloatNodeImpl.cpp
